Battery-Bohrschrauber C 18 Li 5,2 Set

Form. Perfect.

18-volt power at its best. The unique C-design with its optimal center of gravity sits perfectly balanced in the hand. Brushless EC-TEC motor technology ensures top performance. The interplay of lithium-ion battery packs and the brushless EC-TEC motor makes the C 18 light, powerful, and durable. The CENTROTEC quick-change system and FastFix attachments ensure even faster workflows, while the fully electronic torque setting with memory switch function ensures repeatable screwdriving.

• Brushless EC-TEC motor with integrated motor management for a long service life and maximum performance

• Fully electronic torque setting and shutdown for precise screwdriving

• FastFix interface for all FastFix attachments and CENTROTEC quick-change tool system

• Switching from screwdriving to drilling without adjusting the set torque

• Convincing ergonomics: short, lightweight, and with an optimal center of gravity

• High-quality lithium-ion battery technology for maximum endurance

• Maximum flexibility and cost-effectiveness: Battery packs of the same voltage class can be used

Product highlights

• Faster to the best Result

Brushless EC-TEC motor with intelligent motor management that accesses the individually optimal power reserves for each screwdriving process.

• Comfortable and safe

Precise screwdriving, quick transition to drilling thanks to electronic torque cut-off with memory switch function.

• Better in the system

One for all – the 5.2 Ah Li-Ion battery packs of the C 18 can be used in all cordless tools of the same class. And vice versa.

Product details

• Power meets intelligence

Festool has combined EC-TEC motor technology with intelligent motor management, thus significantly advancing the product. The brushless EC-TEC motor operates wear-free and converts the battery's energy into power with virtually no loss.

This gives the C 18 an enormous level of efficiency in its performance class. In addition, the electronic motor management system guarantees a longer service life. Microprocessors monitor and control the temperature, voltage, and current consumption of the motor, electronics, and battery. • Precise work • The handy and perfectly balanced C-design allows for very precise positioning thanks to the handle's position in the drilling and screwing axis. • In short: The torque setting and shut-off are integrated directly into the patented compact gearbox. This saves space and ensures maximum power transmission.

• When space is tight

As with all Festool cordless drill/drivers, the bits on the C 18 can be inserted into the direct spindle mount.

• 6 bits always at hand

The practical bit garage offers space for up to six bits in the mount – magnetically secured to prevent them from falling out.

• In the tightest of spaces

The angle attachment is ideal for screwing around corners and for reaching hidden screws in tight angles.

• Edge to edge

With the eccentric attachment, every screw is accessible.

• CENTROTEC quick-change system

Switch between drilling, countersinking, and screwing more quickly. The CENTROTEC quick-change system is a drill chuck and bit holder in one, and is 50% smaller and 80% lighter than a standard drill chuck. The hexagonal tools are centered with balls – for optimal power transmission and 10 times higher concentricity.

• Drill chuck for standard tools

The drill chuck with a standard width of up to 13 mm also allows the use of all standard bits and drills. Tool-free assembly via the FastFix interface.

• Optimum power development

Fully electronic torque settings and shutdown for optimal power development in all work situations. The set torque for screwdriving is retained, even when drilling at maximum torque in between.

• Optimally illuminated

The integrated LED light allows precise work even in dark corners.

• Don't flaunt with Ah. Show off with power

The new Festool Li-Ion 5.2 Ah battery pack with AIRSTREAM. The new AIRSTREAM technology guarantees faster reuse of the battery packs and thus uninterrupted work – even with energy-intensive applications such as sawing. This is because the new battery packs feature an integrated cooling channel, which, when used in conjunction with the new SCA 8 rapid charger, shortens the cooling time and thus the entire charging process by up to 65%. They are also extremely robust, with an integrated rubber frame to protect the workpiece and the battery pack, and thanks to the charge level indicator, the remaining capacity is always directly visible.

• The new TCL 6 and SCA 8 rapid chargers with AIRSTREAM technology

The new TCL 6 and SCA 8 rapid chargers with charge level indicators charge quickly and are gentle on the battery. In addition to their compact design, they feature practical cable storage and the option of easy wall mounting. They are also extremely robust thanks to fully encapsulated electronics. The SCA 8 fast charger (included with the Plus SCA and Set versions) also features AIRSTREAM technology, which shortens the charging process by up to 65% through targeted cooling of the battery pack. An LED display on the device provides information about the remaining charging time in minutes and the charging status.

Main areas of application

• Furniture and kitchen assembly

• Installation of fittings, back panels, and moldings

• Installation of doors and windows, drilling and screwing in wood, metal, and plastic

• Erection of fences, pergolas, carports, and canopies

• Construction of wooden substructures

Features

• Electronic

Adjustable speed for material-specific work.

• FastFix

Facilitates the changing of insert tools when milling, sawing, planing, sanding, drilling, and screwing.

• Torque cut-off

Intelligent technology delivers the optimal screwdriving power for every material.

• Lithium-ion battery

Equipped with Lithium-ion high-performance battery packs.

• EC-TEC motor

The EC-TEC drive concept stands for exceptional power development with the lowest possible energy consumption.

• AIRSTREAM

Faster reuse of battery packs thanks to AIRSTREAM technology (cooling function for faster availability) and significantly increased charging capacity

Technical data

• Battery voltage: 18 V

• Gears: 2

• Idle speed 1st/2nd gear: 0 - 450/0 – 1,500 min⁻¹

• Drilling diameter wood/steel: 40/13 mm

• Torque setting 1st/2nd Gear: 0.8 - 8/0.5 - 6 Nm

• Max. torque wood/steel: 27/45 Nm

• Chuck capacity: 1.5 - 13 mm

• Battery capacity Li-Ion: 5.20 Ah

• Weight with Li-Ion: 1.80 kg

Noise and vibration values

• Drilling in metal: Total vibration mean value ah: 3.50 m/s²

• Drilling in metal: Standard series EN 60745: 60745-2-1/2

• Drilling in metal: Uncertainty (noise) K: 3.00 dB

• Drilling in metal: Uncertainty (vibration) K: 1.50 m/s²

• Drilling in metal: A-weighted sound pressure level Lp: 65.00 dB(A)

• Drilling in metal: A-weighted sound power level Lw: 76.00 dB(A)

• Screwing: Total vibration mean value ah: 2.50 m/s²

• Screwing: Standard series EN 60745: 60745-2-1/2

• Screwing: Uncertainty (noise) K: 3.00 dB

• Screwing: Uncertainty (vibration) K: 1.50 dB(A)

• Screwing: A-weighted sound pressure level Lp: 65.00 dB(A)

• Screwing: A-weighted sound power level Lw: 76.00 dB(A)

Scope of delivery

• Cordless drill/screwdriver in SYSTAINER SYS 2 T-LOC

• 2 x battery pack BP 18 Li 5.2 AS

• Quick charger TCL 6

• Tool chuck WH-CE CENTROTEC

• CENTROTEC bit holder

• Keyless drill chuck FastFix 13mm (KC 13-1/2-K-FFP)

• Bit PZ 2

• Angle attachment DD-AS

• Eccentric attachment DD-ES

• Belt clip
