FRITZ!Powerline 540E WLAN-Set

• Extends the home network via the power line
• Powerline with up to 500 Mbps, securely encrypted
• Ready to use at any power outlet without software installation
• Fast Ethernet for connecting TVs, Blu-ray players, hi-fi systems, and game consoles
• Wi-Fi access point with up to 300 Mbps (2.4 GHz)

FRITZ!Powerline 540E combines fast networking via the power line with the flexibility of Wi-Fi for surfing the web and networking at home. In no time at all, any power outlet becomes a secure and fast network connection with transfer rates of up to 500 Mbps in the power grid.

FRITZ!Powerline connects PCs, printers, TVs, hi-fi systems, Blu-ray players, and other network-capable devices via a LAN port (up to 100 Mbps). The powerful Wi-Fi access point with up to 300 Mbps also allows smartphones, tablets, and other mobile devices to be wirelessly integrated into the home network with high data performance, even across rooms.

Powerline Functions

• Extends the home network via the house's internal power line
• Can be used at any power outlet without software installation
• Up to 500 Mbps* Powerline data rate: robust connections over long network distances
• For bandwidth-intensive applications in multiple rooms: HD video (including 3D), multimedia streaming, Internet access via VDSL and cable
• 2x Fast Ethernet (100 Mbps) for connecting PCs, printers, TVs, Blu-ray players, hi-fi systems, and games consoles
• Quality of Service: Data prioritization for interference-free video transmission and Internet telephony
• Multicast: Supports multicast sessions managed with IGMP
• Factory-securely encrypted: 128-bit AES link encryption and key management
• Compatible with powerline adapters of the 500 and 200 Mbps class and the IEEE P1901 standard, coexistence with older powerline adapters
• Supports IPv6

WLAN functions

• WLAN access point according to IEEE 802.11b (11 Mbps), g (54 Mbps), n (300 Mbps) in the 2.4 GHz frequency band
• Wirelessly connects PCs, tablets, smartphones, Printers and other network-capable devices
• Maximum Wi-Fi security with WPA2 (802.11i), easy setup with WPS (Wi-Fi Protected Setup) at the touch of a button
• Repeater function can be set; increases the range of the Wi-Fi network of the FRITZ!Box and other routers

Web-based user interface

• Easy operation via its own user interface
• Enables settings for Wi-Fi, network, updates, etc.
• Status display and operation via the LED buttons

Dimensions: (W x H x D) approx. 59 x 132 x 41 mm
Weight: approx. 185 g
Power consumption: approx. 5 to 6 watts typical
