Scie circulaire de chantier "PBK 500", 3000 watts

• Adjustable working height and individually height-adjustable feet
• Transportable with crane eyes or hand pallet truck
• Connection for dust extraction system and longitudinal stop
• Measuring scale and push stick
• Foldable sliding carriage with miter angle

Construction saws like the "PBK 500" have several advantages over scroll saws or band saws. First, there's the larger saw blade. This table saw features a generous carbide saw blade. The blade diameter is 500 millimeters. This allows for a cutting height of 175 millimeters. The working height is also adjustable. Furthermore, the circular saw blade does not give way under pressure. The included push stick allows you to further increase the accuracy of recurring cuts. The large table, measuring one meter wide, also makes the Güde table saw stand out here. This allows for more flexible working compared to hand-held circular saws. In terms of efficiency, the "PBK 500" is far superior to many hand saws.

Especially when making many identical cuts. With a little practice, astonishing sawing speeds can be achieved. Regardless of whether it's soft, hard, or solid wood. The Güde "PBK 500" table saw is no lightweight at around 100 kilograms and is therefore designed for stationary use. Nevertheless, the manufacturer has thought ahead. For example, crane eyes are located on the saw for possible transport. Moving the machine using a hand pallet truck is also no problem. For even more customized work, the feet of the Güde model can be individually adjusted in height. Practical! In addition, commercially available dust extraction systems can be connected. In addition to a longitudinal stop and push stick, the scope of delivery also includes a measuring scale and a foldable sliding carriage. The latter integrates a useful miter angle.

Technical data

• Mains voltage: 400 Volt
• Frequency: 50 Hertz
• Operating mode: S6 40%
• Protection class (IP): 54
• Motor power (P1): 3.0 kW
• Max. Cutting height: 175 mm
• Saw blade speed: 2800 min-1
• Saw blade bore: 30 mm
• Saw blade type: HM
• Number of teeth: 44

Dimensions: approx. 1060 x 815 x 1200 mm

• Table: approx. 1000 x 855 - 970 x 760 mm
• Extension: approx. 720 x 400 mm
• Saw blade diameter: approx. 500 mm
• Cutting capacity: approx. 175 mm

Weight: approx. 103.3 kg

Scope of delivery

• 1 x construction circular saw "PBK 500"
• 1 x HM saw blade
• 1 x operating instructions
