Bench lathe ED300ECO 230 Volt
| Référence article | WF-892194 |
| Marque | Holzmann |
Il n'y a pas encore d'avis — le vôtre pourrait être le premier
Partagez votre expérience avec cette achat et aidez d'autres clients à faire le bon choixIl n'y a pas encore de questions
Poser une question pour en savoir plus sur le produit
0.0
Do it yourself model with compact design
- With lead screw for thread cutting or automatic longitudinal turning
- Prism bed guides induction hardened and precision ground
- Hardened main spindle mounted in adjustable, precise tapered roller bearings
- High concentricity of the main spindle (< 0.009 mm)
- Speed continuously adjustable
- Metal change gears supplied as standard for a large thread cutting range
- Powerful, maintenance-free motor with undervoltage release
- Right-left rotation can be switched on the control panel
- Tailstock can be moved for taper turning
- Drill chuck diameter 80 mm
Motor data
Motor power S1 in W 400
Motor power S6 in W 560
Voltage 230V 50Hz
General dimensions &nb sp;
Installation dimensions in mm &nb sp; &nb sp; 760x230x254
Lathes
Center width in mm & nbsp; &nb sp; &nbs p; 300
Center height in mm &nb sp; &nb sp; 90
max. swing diameter bed in mm
180
max. swing diameter cross slide in mm 105
Rotating spindle speed in min-1 50-2500
Spindle bore in mm 20
Spindle holder MK3
Tailstock cone &nbs p; &nb sp; & nbsp; MK2
Travel distance of longitudinal slide in mm 275
Cross slide travel in mm 70
Travel distance of upper slide in mm 70
Quill travel in mm 50
Thread Metric in mm/r 0.5-2.5
max. tool holder 8
Weight
Net weight in kg & nbsp; &nb sp; &nbs p; 40
Gross weight in kg &n e.g. &nbs p; 48
